Atigo A1004 - 2-wire ultra-thin audio handsfree with three buttons

The Atigo A1004 is a 2-wire audio handsfree that has been designed with an ultra-thin body, a handset for privacy and two buttons.

​

This highly functional audio handset has an unlock button, and a secondary button that can be used to unlock a second door or as a call button.

​

For installation: Use the screws to fix the mounting bracket to the wall using the mounting box (The suggested installation height of the unit is 145-160cm). Connect the 2 cables to the unit and then mount it on the stand.

Features :

• Simple and intuitive audio receiver

• Ultra-thin design (17.5mm)

• Made of high quality ABS plastic

​

Technical information :

• Power supply: 26V DC

• Power consumption: Standby 4.4mA; Working 81mA

• Ringtones: 9 distinct ringtones

• Wiring: 2 non-polarized wires

​

Dimensions :

• 138 x 90 x 17.5 mm (hwd)
